PCB auto-routing animation

Why We Built It

Every time we scaled an 8-channel board up to 16 channels, we had to redo the schematic and artwork. Even with proven circuits and a component library already in place, cutting down the repetitive work wasn’t easy.

So we decided to introduce AI automation.

If we could design and route a circuit in less time, we could offer custom boards to many more companies.

KiCad schematic editor screen

What We Built

KiCad component placement screen

  • 1,214 KiCad footprints
  • 857 KiCad symbols
  • 60 components
  • 152 wiring connections
  • 8 input channels / 8 output channels
ItemBefore libraryAfter library
Right-angle bends283
Arbitrary-angle segments7817
Mixed trace widths16 nets0
